GENUINE VW/AUDI/SEAT/SKODA 0B5 DSG 7 SPEED AUTOMATIC TRANSMISSION DUAL CLUTCH

OUR TEAM OF SPECIALIST ARE ON HAND TO GIVE PROFESSIONAL AND FRIENDLY ADVICE

OUR OPENING HOURS:

MONDAY: 09:00-18:00
TUESDAY: 09:00-18:00
WEDNESDAY: 09:00-18:00
THURSDAY: 09:00-18:00
FRIDAY: 09:00-18:00
SATURDAY: 09:00-14:00
SUNDAY: CLOSED

CONTACT US

0b5 clutch is used in 4WD vehicles, mainly in Audi A4, A5, A6, A7, and in Porsche Macan. DSG7 0B5 AT is one of the first robotic transmissions produced by VAG, it is installed on cars with longitudinal engines and powerful motors. You can order a clutch package and other original spare parts from leading manufacturers in our online store.

Clutch dsg 7: unit characteristics

DSG7 0B5 (DL501) is a seven-speed robotic transmission with dual wet clutch that allows gear shifting without interrupting the power flow. The clutch is used to transmit torque to the input shaft. The double clutch allows the transmission of torque alternately to the two circuits of the input shaft.

The dl501 clutch consists of two packages: K1 and K2. The clutch is located in oil bath and consists of a set of clutches, a set of steel discs, baskets, and pistons. The mechatronics solenoid valves apply pressure to the clutch, the clutch is depressed, and the 1-3-5-7 gear package and the 2-4-6 reverse gear package are activated. The average DSG7 0B5 clutch resource is around 100- 120 thousand km.

For a seven-speed DSG transmission, you can also use a DSG dry clutch, a robotic gearbox with a dry dual clutch allowing to shift gears without interrupting the flow of power.

Order clutch in GearboxOils online store.

You can make your order using online catalog or fill in our feedback form. We offer TOP quality products from leading manufacturers. You can also get detailed consultation, technical support, and order a DQ200 clutch kit by contacting us.
